Product Description
High-quality hydraulic products, including KHB Ball Valves. Our ball valves are designed for precision control and durability in various hydraulic applications. For reliable performance.
- Working pressure up to 700bar.
- Also manufactured in stainless steel.
Main features of KHB ball valves are:
- 2 way 2 position ;
- build with high strength material-C45 Carbon Steel;
- various connecting thread available: BSPP, BSPT, NPT, SAE-UNF, LR/SR, METRIC;
- 3 pieces structure, floating ball, which provide positive sealing under high pressure;
- blow out proof stem, high safety factor;
- Zero leakage;
- Working pressure up to 700 Bar, safety factor 3.1;
- working temperature up to 170/338 (Viton O-ring);
- direct interchangeable with other international brands;
KHB ball valves Description
- Series Code: KHB(BKH)
- Joint Code: M,G,LR,SR,PT,NPT
- Valve Body Material: 1-Steel
- Ball Body Material: 1-Steel, 2-Brass
- Operating Temperrature: 1.-25+100 -30+170
- Other Airproof: 2-NBR, 4-FPM
- Handle Type: 01-Aluminium straight handle, 02-Aluminium crooked handle, 03-Casting zinc straight handle, 04-Casting zinc crooked handle, 05-Steel straight handle, 06-Steel crooked handle, 09-Without handle
- Design Number: To be decided by the manufacturer
- Surface Dispossal: Blank-Phosphoric polish, G-Electroplated yellow zinc
- Applicable Medium: Hydraulic Oil
